ASAŞ Curtain Wall RPE82
ASAŞ Curtain Wall RPE82
ASAŞ Curtain Wall RPE82
    ASAŞ

    ASAŞ Curtain Wall RPE82

    RPE82 Panel Façade System is used as a curtain wall system in structures such as high-rise office buildings, hotels, hospitals, residential complexes, and public buildings due to the speed and ease of installation it provides in tall buildings. Since assembly is carried out in a factory setting, it offers significant advantages in terms of labor efficiency and quality control. Instead of installing components separately, a single panel — which may include horizontal and vertical profiles along with glass and composite elements — is preassembled in the factory to span one floor height and several horizontal sections, and is then installed on the building as a ready-to-use unit.

    Specification
    • Technical Properties:

      Profile Width: 36 mm - max. 87 mm

      Mullion Depths: 137 mm - max. 182,7 mm

      Transom Depths: min. 133,5 mm - max. 169 mm

      Wall Thickness: 2 mm

      Max. Glass Thickness: 35 mm

      Application Options:

      Facade With Cap

      Structural System

      Parallel Opening Vent

      All colors are applicable for electrostatic powder painting and anodizing surface processes.

    Technical specification
    • Unique ref.asas-curtain-wall-rpe82
    • TypeObject (single object)
    • Date of publishing2025-05-06
    • Edition number1
    Related
    • Material mainAluminium
    • Material secondaryGlass
    • Designed inTürkiye
    • Manufactured inTürkiye
    Classification
    • BIMobject CategoryWalls - Curtain Walls
