TRAIL Ceiling mounted recessed

Trail is the ideal solution for indoor and outdoor linear lighting wherever light quality, reliability and energy efficiency are required. #Light quality [1] The quality of the sources and the special linear optical system ensure that the light output is homogeneous and the materials give a high colour rendering index. [2] When installed side-by-side in a continuous line, Trail modules ensure continuous, even distribution without any shadows on the illuminated surfaces. [3] The ultra-wide beam version has an anti-glare screen that diffuses the light to ensure high visual comfort. #Flexibility [1] Trail Ceiling Recessed is available in two lengths and can be installed as a single module or in a continuous line. [2] It has a very small recess depth so that it can be housed in any false ceiling. #Attention to detail The heads of each individual product are very small to minimise the break in light due to the joint between modules. #Easy to install A single power cable can power multiple Trail modules. The individual connections to each fitting branch off through watertight connectors mounted on the single cable. The watertight plug-socket ensures simple, quick and safe installation. #DURABLE The product is robust and reliable. Components, materials and finishes have been chosen to last a long time and resist corrosion, infiltration and mechanical impact.
Spezifikation
  • Trail is the ideal solution for indoor and outdoor linear lighting wherever light quality, reliability and energy efficiency are required. #Light quality [1] The quality of the sources and the special linear optical system ensure that the light output is homogeneous and the materials give a high colour rendering index. [2] When installed side-by-side in a continuous line, Trail modules ensure continuous, even distribution without any shadows on the illuminated surfaces. [3] The ultra-wide beam version has an anti-glare screen that diffuses the light to ensure high visual comfort. #Flexibility [1] Trail Ceiling Recessed is available in two lengths and can be installed as a single module or in a continuous line. [2] It has a very small recess depth so that it can be housed in any false ceiling. #Attention to detail The heads of each individual product are very small to minimise the break in light due to the joint between modules. #Easy to install A single power cable can power multiple Trail modules. The individual connections to each fitting branch off through watertight connectors mounted on the single cable. The watertight plug-socket ensures simple, quick and safe installation. #DURABLE The product is robust and reliable. Components, materials and finishes have been chosen to last a long time and resist corrosion, infiltration and mechanical impact.
Technische Spezifikation
  • ReferenznummerTRAIL_ceiling-recessed_mounted
  • ProduktfamilieRecessed
  • ProduktgruppeTrail
  • TypObjekt (Einzelobjekt)
  • Veröffentlichungsdatum2017-12-06
  • Editionsnummer2
  • Höhe (mm)42
  • Breite (mm)1292
  • Tiefe (mm)100
Verwandt
  • HauptmaterialAluminium
  • Sekundär MaterialAluminium
  • Entwickelt inItalien
  • Hergestellt inItalien
  • Nettogewicht (kg)6
Klassifikation
  • BIMobject KategorieBeleuchtungselemente - Deckenbeleuchtungen
  • IFCClassificationLeuchten
  • ETIM CodeEC001959
  • ETIM NameLED-lamp/Multi-LED
  • UNSPSCNameLighting Fixtures and Accessories
  • UNSPSCCode3911
  • Classifications.Uniclass2015CodePr_70_70_48_46
  • Classifications.Uniclass2015BeschreibungLight-emitting diode (LED) luminaires
  • ProductPage.DetailedInfo.Classifications.COBIetypeCategoryPr_70_70_48_46
  • Klassifizierung26 56 00
  • Format2014TitelExterior Lighting
  • OmniClassNummer23-35 47 11
  • OmniClassTitelLighting Fixtures
  • CSIUniFormatIICodeD5020
  • CSIUniFormatIITitleLighting & Branch Wiring
