    JCK227 belongs to a series of elbow switches with dual push surfaces, allowing connection to, for example, an additional door or a lock. JCK227 is made of silver-anodized aluminum with black end caps. Both push surfaces feature four tactile grooves, serving as additional guidance for individuals with visual impairments. It’s easy to feel where to press to activate the door opening.

    Specifikation
    • Manufactured in Sweden.

      Material: Alu.6060-T6, POM Plastic (Acetal plastic).

      Dimensions, standard version (L/W/H): 311 x 80 x 23 mm.

      Micro switches: 1 pc NO and 1 pc NO/NC. IP67.

    Teknisk specifikation
    • Unik ref.elbow-switch-jck227
    • ProduktfamilieMetal
    • ProduktgruppeAluminum
    • TypeObjekt (enkelt objekt)
    • Udgivelsesdato2025-05-15
    • Udgavenummer1
    • Højde (mm)311
    • Bredde (mm)80
    • Dybde (mm)23
    Relateret
    • Materiale primærtAluminium
    • Materiale sekundærtCopolymer
    • Designet iSverige
    • Fremstillet iSverige
    • Nettovægt (kg)0.4
    Klassifikation
    • BIMobject-kategoriDøre - Automatisk åbning
    • IFC-klassifikationDør
    • ETIM-kodeEC001351
    • ETIM-navnPush button panel door communication
    • Uniclass 2015-kodePr_75_51_17_66
    • Uniclass 2015-beskrivelsePush button switches
    • CSI MasterFormat 2014-kode40 78 19
    • CSI MasterFormat 2014-titelSwitches and Push Buttons
    • OmniClass-nummer23-35 37 49
    • OmniClass-betegnelsePush Button Switches
